FSJ1-50A
FSJ1-50A, HELIAX® Superflexible Low Density Foam Coaxial Cable, corrugated copper, 1/4 in, black PE jacket
Specifications
Product classification
| Product Type | Coaxial wireless cable |
| Product Brand | HELIAX® | SureFlex® |
| Product Series | FSJ1-50A | MLOC |
General specifications
| Product Number | 887009902/00 | SZ887009902/00 |
| Flexibility | Superflexible |
| Jacket Color | Black |
| Performance Note | Attenuation values typical, guaranteed within 5% |
Dimensions
| Diameter Over Dielectric | 4.826 mm | 0.19 in |
| Diameter Over Jacket | 7.366 mm | 0.29 in |
| Inner Conductor OD | 1.905 mm | 0.075 in |
| Outer Conductor OD | 6.35 mm | 0.25 in |
| Nominal Size | 1/4 in |
Electrical specifications
| Cable Impedance | 50 ohm ±1 ohm |
| Capacitance | 79.4 pF/m | 24.201 pF/ft |
| dc Resistance, Inner Conductor | 9.843 ohms/km | 3 ohms/kft |
| dc Resistance, Outer Conductor | 7.216 ohms/km | 2.199 ohms/kft |
| dc Test Voltage | 1600 V |
| Inductance | 0.2 µH/m | 0.061 µH/ft |
| Insulation Resistance | 100000 MOhms-km |
| Jacket Spark Test Voltage (rms) | 5000 V |
| Operating Frequency Band | 1 – 18000 MHz |
| Peak Power | 6.4 kW |
| Velocity | 82 % |
Material specifications
| Dielectric Material | Foam PE |
| Jacket Material | PE |
| Inner Conductor Material | Copper-clad aluminum wire |
| Outer Conductor Material | Corrugated copper |
Mechanical specifications
| Minimum Bend Radius, multiple Bends | 25.4 mm | 1 in |
| Minimum Bend Radius, Single Bend | 25.4 mm | 1 in |
| Number of Bends, minimum | 15 |
| Number of Bends, typical | 20 |
| Tensile Strength | 68 kg | 149.914 lb |
| Bending Moment | 0.7 N-m | 6.196 in lb |
| Flat Plate Crush Strength | 1.8 kg/mm | 100.795 lb/in |
Environmental specifications
| Installation temperature | -40 °C to +60 °C (-40 °F to +140 °F) |
| Operating Temperature | -55 °C to +85 °C (-67 °F to +185 °F) |
| Storage Temperature | -70 °C to +85 °C (-94 °F to +185 °F) |
| Attenuation, Ambient Temperature | 20 °C | 68 °F |
| Average Power, Ambient Temperature | 40 °C | 104 °F |
| Average Power, Inner Conductor Temperature | 100 °C | 212 °F |
Packaging and weights
| Cable weight | 0.07 kg/m | 0.047 lb/ft |
Regulatory compliance/certifications
| Agency | Classification |
CHINA-ROHS
|
Below maximum concentration value |
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
| ROHS | Compliant |
| UK-ROHS | Compliant |
UL/ETL Certification
|
Compliant |
| REACH-SVHC | Compliant as per SVHC revision on www.andrew.com/ProductCompliance |
