AVA5P-50-C | 520093702/00
AVA5-50, HELIAX® Andrew Virtual Air™ Coaxial Cable, corrugated copper, 7/8 in, black PE jacket (Halogen free jacketing non-fire-retardant) tested C-Band and CBRS qualified.
Specifications
Product classification
| Product Type | Coaxial wireless cable |
| Product Brand | HELIAX® |
| Product Series | AVA5-50 |
| Ordering Note | ANDREW® standard product (Global) |
General specifications
| Flexibility | Standard |
| Jacket Color | Black |
| Performance Note | Attenuation values typical, guaranteed within 5% |
| Specification Sheet Revision Level | B |
Dimensions
| Diameter Over Dielectric | 24.13 mm | 0.95 in |
| Diameter Over Jacket | 27.991 mm | 1.102 in |
| Inner Conductor OD | 9.4488 mm | 0.372 in |
| Outer Conductor OD | 25.4 mm | 1 in |
| Nominal Size | 7/8 in |
Electrical specifications
| Cable Impedance | 50 ohm ±1 ohm |
| Capacitance | 73 pF/m | 22.25 pF/ft |
| dc Resistance, Inner Conductor | 1.435 ohms/km | 0.437 ohms/kft |
| dc Resistance, Outer Conductor | 1.116 ohms/km | 0.34 ohms/kft |
| dc Test Voltage | 6000 V |
| Inductance | 0.184 µH/m | 0.056 µH/ft |
| Insulation Resistance | 100000 MOhms-km |
| Jacket Spark Test Voltage (rms) | 8000 V |
| Operating Frequency Band | 1 – 5000 MHz |
| Peak Power | 91 kW |
| Velocity | 91 % |
Material specifications
| Dielectric Material | Foam PE |
| Jacket Material | PE |
| Inner Conductor Material | Copper tube |
| Outer Conductor Material | Corrugated copper |
Mechanical specifications
| Minimum Bend Radius, multiple Bends | 254 mm | 10 in |
| Minimum Bend Radius, Single Bend | 127 mm | 5 in |
| Number of Bends, minimum | 15 |
| Number of Bends, typical | 30 |
| Tensile Strength | 159 kg | 350.535 lb |
| Bending Moment | 19 N-m | 168.164 in lb |
| Flat Plate Crush Strength | 1.3 kg/mm | 72.797 lb/in |
Environmental specifications
| Installation temperature | -40 °C to +60 °C (-40 °F to +140 °F) |
| Operating Temperature | -55 °C to +85 °C (-67 °F to +185 °F) |
| Storage Temperature | -70 °C to +85 °C (-94 °F to +185 °F) |
| Attenuation, Ambient Temperature | 20 °C | 68 °F |
| Average Power, Ambient Temperature | 40 °C | 104 °F |
| Average Power, Inner Conductor Temperature | 100 °C | 212 °F |
Packaging and weights
| Cable weight | 0.45 kg/m | 0.302 lb/ft |
Regulatory compliance/certifications
| Agency | Classification |
CHINA-ROHS
|
Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
| ROHS | Compliant |
| UK-ROHS | Compliant |
Product classification
| Product Type | Coaxial wireless cable |
| Product Brand | HELIAX® |
| Product Series | AVA5-50 |
| Ordering Note | ANDREW® standard product (Global) |
General specifications
| Flexibility | Standard |
| Jacket Color | Black |
| Performance Note | Attenuation values typical, guaranteed within 5% |
| Specification Sheet Revision Level | B |
Dimensions
| Diameter Over Dielectric | 24.13 mm | 0.95 in |
| Diameter Over Jacket | 27.991 mm | 1.102 in |
| Inner Conductor OD | 9.4488 mm | 0.372 in |
| Outer Conductor OD | 25.4 mm | 1 in |
| Nominal Size | 7/8 in |
Electrical specifications
| Cable Impedance | 50 ohm ±1 ohm |
| Capacitance | 73 pF/m | 22.25 pF/ft |
| dc Resistance, Inner Conductor | 1.435 ohms/km | 0.437 ohms/kft |
| dc Resistance, Outer Conductor | 1.116 ohms/km | 0.34 ohms/kft |
| dc Test Voltage | 6000 V |
| Inductance | 0.184 µH/m | 0.056 µH/ft |
| Insulation Resistance | 100000 MOhms-km |
| Jacket Spark Test Voltage (rms) | 8000 V |
| Operating Frequency Band | 1 – 5000 MHz |
| Peak Power | 91 kW |
| Velocity | 91 % |
Material specifications
| Dielectric Material | Foam PE |
| Jacket Material | PE |
| Inner Conductor Material | Copper tube |
| Outer Conductor Material | Corrugated copper |
Mechanical specifications
| Minimum Bend Radius, multiple Bends | 254 mm | 10 in |
| Minimum Bend Radius, Single Bend | 127 mm | 5 in |
| Number of Bends, minimum | 15 |
| Number of Bends, typical | 30 |
| Tensile Strength | 159 kg | 350.535 lb |
| Bending Moment | 19 N-m | 168.164 in lb |
| Flat Plate Crush Strength | 1.3 kg/mm | 72.797 lb/in |
Environmental specifications
| Installation temperature | -40 °C to +60 °C (-40 °F to +140 °F) |
| Operating Temperature | -55 °C to +85 °C (-67 °F to +185 °F) |
| Storage Temperature | -70 °C to +85 °C (-94 °F to +185 °F) |
| Attenuation, Ambient Temperature | 20 °C | 68 °F |
| Average Power, Ambient Temperature | 40 °C | 104 °F |
| Average Power, Inner Conductor Temperature | 100 °C | 212 °F |
Packaging and weights
| Cable weight | 0.45 kg/m | 0.302 lb/ft |
Regulatory compliance/certifications
| Agency | Classification |
|
CHINA-ROHS
|
Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
| ROHS | Compliant |
| UK-ROHS | Compliant |
