VVSSP-45S-R1BV2 VVSSP-45S-R1BV2
10-port small cell antenna, 4x 1695–2690, 4x 3300-4200 and 2x 5150-5925 MHz. 45° HPBW, Internal RET and SBT
VVSSP-45S-R1BV2
  • Product type: Sector antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal beamwidth: 45°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 6
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 0
SpecificationsSpecs
VVSSP-45S-R1BV2
  • Product type: Sector antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal beamwidth: 45°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 6
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 0
VVSSP-65PS-F2 VVSSP-65PS-F2
10-port small cell antenna, 4x 1695-2690, 4x 3100-4200,2x 5150-5925 MHz, bi-directional pattern, fixed tilt.
VVSSP-65PS-F2
  • Product type: Bidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 10
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
VVSSP-65PS-F2
  • Product type: Bidirectional antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 10
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
VVSSP-65S-R1B VVSSP-65S-R1B
10-port small cell antenna, 4x 1695–2690, 4x 3400-3800 and 2x 5150-5925 MHz. 65° HPBW, Internal RET and SBT
VVSSP-65S-R1B
  • Product type: Sector antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 10
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
VVSSP-65S-R1B
  • Product type: Sector antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 10
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
VVSSP-65S-R1BV2-V4 VVSSP-65S-R1BV2-V4
10-port small cell antenna, 4x 1695–2690, 4x 3300-4200 and 2x 5150-5925 MHz. 65° HPBW, Internal RET and SBT
VVSSP-65S-R1BV2-V4
  • Product type: Sector antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 10
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SpecificationsSpecs
VVSSP-65S-R1BV2-V4
  • Product type: Sector antenna | Small cell antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 10
  • Rf connector quantity, high band: 10
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
